Professional Monofilament Screen Printing Mesh Roll 100 % Monofilament Polyester Yarn

Brand Name : R&K

Model Number : H810

Certification : FDA,SGS,MSDS

Place of Origin : Hebei China Mainland

MOQ : 10 square meter

Price : negotiation

Payment Terms : L/C, T/T, Western Union,Paypal,Credit Card,trade assurance

Supply Ability : 10000 meter per months

Delivery Time : within 5 - 7 days ,depends on your quantity

Packaging Details : bubble film and plastic bag inside ,and the carton box outside.

Textile screen mesh Material : 100 % monofilament polyester yarn

Textile screen mesh Thread diameter : 25 micron to 619 micron

Textile screen mesh Mesh count : 30 mesh to 460 mesh

Textile screen mesh Color : white is very popular.,yellow is also ok,

Textile screen mesh Roll length : 50/100/200/300meter

Textile screen mesh Roll width : 41 inch 45 inch 50 inch 65 inch...

Brand name : R&K

Place of origin : Hebei China Mainland

Textile screen mesh MOQ : 1 meter

Contact Now

Professional Monofilament Screen Printing Mesh Roll 100 % Monofilament Polyester Yarn

Textile screen printing information details:

Material: 100% monofilament polyester yarn

Wire diameter: 27 micron - 300 micron,other wire diameter wen can customized on machine.

Mesh count range: 20 mesh to 460 mesh

Popular color:white color,yellow,jacinth.

Roll width:41inch , 45 inch ,50 inch , 65 inch , 71 inch ,90 inch ,130 inch , 144 inch.

Popular mesh count: 24T-100 um, 39T-55 um,43T-80um,54T-55 um, 62T-64um,80T-48 um,90T-48um,100T-40um,120T-34um,120T-31 um,140T -31um,140T-34um,150T-34um,165T-31um,165T-27um.

Max wide:3.65m (144'')

Reking mesh always use high quality yarn to produce the polyester printing mesh,our mesh count have a little tolerance,about +/- 2 mesh. it is very standard. we can accept OEM based on clinet requirement.

Textile screen printing application:

Textile screen printing are wilde used in textile industry printing,garment industry printing,Image printing,electronic compenents chips, PCB,touch screen printing.advertising ,metal sheet printing. glass bottle printing.

Specification of the 25 micron mesh:

specification	Mesh count	Thread diameter	Mesh opening	Open surface	Fabric thickness	Weight
180T-27(PW)	460mesh	27 micron	28 micron	28%	41micron	29g/m2
165T-31(PW)	420mesh	31 micron	23micron	15%	48micron	36g/m2
150T-31(PW)	380mesh	31 micron	32micron	23%	49micron	32g/m2
150T-34(PW)	380mesh	23micron	34micron	13%	55micron	42g/m2
120T-31(PW)	305mesh	31micron	49micron	35%	49micron	26g/m2
120T-40(PW)	305mesh	40micron	37micron	20%	63micron	44g/m2
90T-48(PW)	230mesh	48micron	56micron	25%	78micron	50g/m2
62T-64(PW)	155mesh	64micron	90micron	31%	101micron	58g/m2
43T-80(PW)	110mesh	80micron	149micron	41%	130micron	64g/m2

Other specification as below:

Mesh Count Diameter (Mesh/cm um)	Mesh Count (Mesh/inch)	Aperture (um)	Thread Diameter (um)	Opening (%)	Thickness (um)	Thickness Tollerance (+/- um)	Theoretical Ink (cm3/m2)	Weight (g/m2)	Tension value (N/CM)
165-31PW(S)	420	23	31	15	48	2	7	36	25-26
150-34PW(T)	380	23	34	13	55	3	6.5	42	30-31
150-31PW(S)	380	32	31	23	49	3	11	32	24-25
140-34TW(T)	355	33	34	21	56	3	12	41	27-28
140-34PW(T)	355	31	34	20	53	3	10	39	26-28
140-31PW(S)	355	36	31	26	48	2	12	30	22-24
130-34PW(T)	330	40	34	27	55	3	15	37	27-28
120-40PW(HD)	305	37	40	20	63	3	13	44	33-35
120-34PW(T)	305	45	34	30	55	3	16	35	25-26
120-31PW(S)	305	49	31	35	49	3	17	26	20-23
110-40PW(HD)	280	48	40	27	64	3	17	40	30-32
100-40PW(T)	255	58	40	33	63	3	21	37	26-27
90-48PW(T)	230	56	48	25	78	4	19	50	34-35
80-48PW(T)	200	72	48	33	74	4	25	56	34-35
77-55PW(T)	195	67	55	27	88	4	24	55	37-38
77-48PW(S)	195	77	48	35	80	4	28	42	34-35
72-55PW(T)	182	85	55	30	90	5	27	51	33-34
72-48PW(S)	182	90	48	36	78	5	33	39	32-33
68-64PW(T)	175	78	64	28	105	5	30	65	39-40
68-55PW(S)	175	85	55	34	85	4	28	48	33-34
64-64PW(T)	160	85	64	30	115	6	34	61	34-35
64-55PW(S)	160	98	55	38	98	5	36	48	33-34
61-64PW(T)	155	90	64	31	101	5	30	58	35-36
54-70PW(HD)	137	109	70	35	116	6	40	62	39-40
54-64PW(T)	137	115	64	39	100	5	39	51	33-34
53-55PW(S)	135	133	55	50	86	6	42	40	26-27
53-45PW(S)	135	143	45*2	57	79	7	41	46	26-27
48-70PW(T)	122	133	70	41	115	6	47	55	34-35
47-55PW(S)	120	152	55	51	88	6	48	34	26-27
43-80PW(T)	110	149	80	41	130	7	53	64	43-44
39-55PW(S)	100	177	55	56	88	6	55	30	39-40
36-90PW(T)	92	183	90	44	150	8	65	68	36-39
32-100PW(T)	81	212	100	45	165	8	73	75	35-37
32-64PW(S)	81	248	64	63	95	6	56	32	26-28
32-55PW(S)	81	257	55	67	103	6	67	28	24-25
28-140PW(SL)	70	217	140	40	195	13	76	125	/
24-100PW(T)	60	316	100	57	136	11	65	81	/
21-150PW(SL)	55	326	150	46	260	14	118	121	/
21-80PW(S)	55	296	80	69	120	9	79	35	/
13-150PW(SL)	33	619	150	64	300	14	128	60	/
PW:TW:SL；S,T,HD PW:(Plain Weave);TW:(Twill Weave); S,T,HD:(thickness of Mesh) Standard Color: white and yellow, other colors on request.
